CT-102 Dry Film Lubricant

Category: Dry Film Lubricant

CT-102 Dry Film Lubricant

Description

CT-102 is a Dry Film Lubricant coating with lubricating solids. CT-102 provides solid lubrication of parts subject to torque or contact stresses. It is not affected by dust or dirt. This is to be used in combination with oil, grease or paste. It provides intermittent dry lubrication properties.

Federal Firearms Licensee (FFL)

Substrate(s)

  • Tin
  • Lead
  • Aluminum
  • Steel
  • Stainless Steel

Temp. Ratings

  • Process Temp: 400°(204°C)
  • Max Temp: 400°(204°C)

Thickness

  • Thickness (mil): 0.2 - 0.5

Color(s)

  • Gray
  • Black

Process

CT-102 Dry Film Lubricant coating is applied as a spray process. Different surface preparatory methods appropriate for the substrates are used prior to the coating process. Coating thickness is varied to suit the application. Typical coating thickness varies from 0.2 - 0.5 mil up to three coats. Coating consists of phenolic resins with MoS2.

Advantages

Not affected by dust or dirt, Low friction, Provides intermittent dry lubrication, Excellent load carrying capacity, Thin coating to accommodate assembly constraints. CT-102 meets MIL-PRF-46010F Type 2.

  • Corrosion Protection
  • Increased Lubricity
  • Low Coefficient of Friction
  • Oil and Fuel Resistant

Applications

Recommended applications include, but are not limited to the following:

  • Bushings
  • Engine Bearings
  • Hinges
  • Springs
  • Slides
  • Spindles
  • Nuts and Bolts
  • Gears
  • Camshafts
  • Locks
  • Switches
  • Valve Springs
  • Oil Pumps

Industries

This coating is a popular solution for the following industries:

  • Aerospace
  • Automotive
  • Chemical
  • Diesel
  • Energy
  • General Manufacturing
  • Marine
  • Metal Forming
  • Military
  • Molds
  • Motorsports
  • Nuclear
  • Oil and Gas
  • Weaponry
